Integrating Test Data from APIs, CSV Files, and Databases into AskUI Workflows

Integrating Test Data from APIs, CSV Files, and Databases into AskUI Workflows
Johannes Dienst
July 24, 2023
linkedin iconmail icon

Are you struggling to integrate test data into your AskUI workflows effectively? Do you find yourself juggling APIs, CSV files, and databases without a clear approach?

Integrating test data from various sources can be a daunting task.

By the end of this post, you'll have a foundation for integrating test data into your AskUI workflows using APIs, CSV files, and databases.

Integrate API

To use an API for fetching test data, you'll need a library like `axios`. After installing it, import it into your AskUI workflow file and use it to call an API, extract data, and insert it into a text field.

-- CODE language-ts line-numbers -- import axios from 'axios'; const url = ''; const data = await axios.get(url); await aui.typeIn([0].name) .textfield() .contains() .text() .withText('E-Mail Address') .exec();

Reading from CSV Files

For integrating CSV files and databases, let's dive into a combined example. Begin by installing the required libraries and adding the necessary imports to your AskUI workflow file. First, read the CSV file into your code and parse it:

-- CODE language-ts line-numbers -- // Top of your workflow file import * as fs from 'fs'; import csv from 'async-csv'; const csvData = fs.readFileSync("./data.csv"); const rows = await csv.parse(csvData);

Our CSV data looks like this. Save it as `data.csv` in the root-folder of your AskUI project:

-- CODE language-ts line-numbers -- year_month,month_of_release,passenger_type,direction,sex,age,estimate,standard_error,status 2001-01,2020-09,Long-term migrant,Arrivals,Female,0-4 years,344,0,Final 2001-01,2020-09,Long-term migrant,Arrivals,Male,0-4 years,341,0,Final 2001-01,2020-09,Long-term migrant,Arrivals,Female,10-14 years,459,0,Final 2001-01,2020-09,Long-term migrant,Arrivals,Male,10-14 years,510,0,Final 2001-01,2020-09,Long-term migrant,Arrivals,Female,15-19 years,899,0,Final 2001-01,2020-09,Long-term migrant,Arrivals,Male,15-19 years,904,0,Final

Create and Initialize Database

Next, create a database on your file system, within the same project as your Ascii workflow file. Set up a schema by opening the database and creating a table:

-- CODE language-ts line-numbers -- // Top of your workflow file import * as aadb from 'aa-sqlite'; // Open a new database const filepath = "./data.db"; await; // Create a table await` CREATE TABLE migration ( year_month VARCHAR(10), month_of_release VARCHAR(10), passenger_type VARCHAR(50), direction VARCHAR(20), sex VARCHAR(10), age VARCHAR(50), estimate INT ) `);

Once completed, you'll have successfully integrated test data into your AskUI workflow using both CSV files and databases.

Insert Data into Database

Now that we have our database and table set up, we'll insert the parsed CSV data into the database. To do this, iterate over each row of the CSV data and use a SQL statement to insert it:

-- CODE language-ts line-numbers -- for (const row of rows) { await` INSERT INTO migration ( year_month, month_of_release, passenger_type, direction, sex, age, estimate ) VALUES (?, ?, ?, ?, ?, ?, ?)`, row.year_month, row.month_of_release, row.passenger_type, row.direction,, row.age, row.estimate ); }

If you don't have a CSV file, you can follow a similar approach to the previous example, where you read data directly from the database and integrate it into your code like this:

-- CODE language-ts line-numbers -- // Get all the data const dataAsync = await aadb.all('select * from migration;'); console.log(dataAsync);


We provided examples of incorporating test data into your AskUI workflow using APIs, CSV files, or databases. While these examples are not comprehensive, they serve as a solid starting point for integrating test data into your projects.
